    GTC12A

    GTC12A – Universal Input, Analog Output, PID Control Device

    Digital calibration technology for input measurement.

    Supports various thermocouples, RTC, DC voltage, DC current.

    Auto tuning (AT) control.

    Provides flexibility and ease of installation.

    User-friendly operating interface.

    Easily adaptable to your panels with 24VDC power supply.

    Developed anti-interference capability for operation in harsh industrial environments.

    Power Supply 24VDC (-15%, +10%)
    Power Consumption ≤5W
    Supported Sensor Types Analog: 4-20mA/0-20mA Thermocouple: J, K, S, R, E, T, B, N, WRe3-WRe25, WRe5-WRe26, Cu50, Pt100
    DC Voltage 0 ~ 5V, 1 ~ 5V, 0 ~ 1V, 0 ~ 100mV, 0 ~ 20mV, 0 ~ 500mV, etc.
    DC Current 4~20mA (with an external 250Ω shunt resistor mounted on the sensor input channel of the device)
    Reading Range J(0~1000°C), K(-50~1300°C), S and R (-50~1700°C), T(-200~+350°C), E(0~800°C), B(200~1800°C), N(0~1300°C), Cu50(-50~+150°C), Pt100(-200~+600°C)
    Measurement Accuracy 0.25%FS ±1 unit of measurement
    Control Mode On-Off control mode (adjustable hysteresis). Fuzzy logic PID control, AI-PID (automatic tuning with advanced AI algorithm).
    Output Features 4-20mA, 0-20mA
    Alarm Function Upper limit, lower limit, deviation upper limit, and deviation lower limit
    Electromagnetic Compatibility (EMC) According to IEC61000-4-4 ±4KV/5KHz; according to IEC61000-4-5 4KV.
    Isolation Withstand Voltage ≥600V between terminals.
    Operating Conditions Temperature -10~60°C, Humidity ≤90%RH
    Communication RTU: RS485 9600,8,None,1
    Mounting Information DIN RAIL Mounting
