    GTC41S-PT – 4 Channel PT-100 Input, 4 Channel SSR Output, PID Control Device

    Digital calibration technology for input measurement

    4 channel PT-100 input

    4 channel SSR output

    Auto tuning (AT) control

    DIN rail mounting

    User-friendly operating interface

    Easily adaptable to panels with 24VDC power supply

    Improved anti-interference capability for operation in harsh industrial environments



    Power Supply 24VDC (-15%, +10%)
    Power Consumption ≤5W
    Supported Sensor Types Pt100
    Reading Range Pt100(-200~+800℃), Pt100(-80.00~+300.00℃)
    Measurement Accuracy 0.25%FS ±1 measurement unit
    Control Mode On-Off control mode (adjustable hysteresis). Fuzzy logic PID control, AI-PID (advanced artificial intelligence algorithm) with automatic adjustment.
    Output Features Control Outputs: 4 SSRs (12VDC), Alarm Outputs: 2 Relays (220VAC)
    Alarm Function Upper limit, lower limit, deviation upper limit, and deviation lower limit
    Electromagnetic Compatibility (EMC) IEC61000-4-4 compliant ±4KV/5KHz; IEC61000-4-5 compliant 4KV.
    Isolation Endurance Voltage Between terminals ≥600V.
    Operating Conditions Temperature -10~60℃, Humidity ≤90%RH
    Communication Modbus RTU: RS485 9600,8,None,1
    Mounting Information DIN RAIL Mounting
