    EMG120 Magnetic Linear Encoders

    EMG120 and EMG121 Magnetic Reader Encoders operate with the EMS110 and EMS200 Series Magnetic Linear Scales. They provide an incremental (encoder/pulse) signal output. The standard resolution is 5 µm (0.005 mm).

    PDF

    Whatsapp
    Emos Group Electronic Machinery Industry | INDUSTRIAL ELECTRONICS, Linear Scales, Sensors, Flow Meters, Central Lubrication Systems, Rotary Encoders, Couplings, Indicators, Potentiometers, Industrial Automation and Control, MACHINE TOOLS, Surface Grinding, EDM Erosion, Band Saws, Boring Machines, Vertical Shapers, Slotting Machines, Tapping Machines, Guillotines, Welding, Compressors, 3D Printers, CNC, Lathe, Milling, Drilling, Presses, Laser, Tool Grinding, QUALITY CONTROL, Single-Axis Measuring Tables, 2-Axis Measuring Tables, 3D Coordinate Measuring Machines, Nuve Coordinate Measuring Tables, Meter Calibration Tables, Length Measuring Tables, Profile Projectors, Video Measuring Devices, Height Gauges, DIGITAL MEASUREMENT SYSTEMS, Digital Measuring Scales, Digital Indicators, Reader Sensors, Digital Measurement System Packages, Battery-Powered Digital Measurement Systems, CNC SPARE PARTS, 3D Sensor, Test Calibration, Spindle Encoder, Battery, Relay, Lubrication Pumps, Foot Pedal, Sensors, Electronic Modules, Switch, Resistor, Power Supplies, Cables, Servo Motors, Encoders, Probes, Magnetic Chucks, Dividers, Handwheels, Mode Switches, Rotary Joints, Slideway Oil Separators, Pulstat Holders, Card Holders, MACHINE LIGHTING, CNC LED Lighting Lamps, Glass Tube LED Lamps, Fluorescent Glass Tube Lamps, LED Lamps with Articulated Arms, Halogen Lamps with Articulated Arms, Flexible Body LED Lamps, Magnetic Base LED Lamps, Flexible Body Halogen Lamps, Magnifying Articulated Lamps
    Önceki Ürün Sonraki Ürün

    EMG120 MAGNETIC LINEAR ENCODERS

    EMG120 Magnetic Reader Encoders operate with EMS110 and EMS200 Series Magnetic Linear Scales.

    They move without contact along the magnetic band at a distance of 0.1 – 2 mm, accurately reading position data and transmitting it as encoder pulses.

    Available in both cabled and coiled models, with or without chip scrapers.

    Supply voltage options: 5V DC - TTL or 24V DC - PPL.

    Provides incremental (encoder/pulse) signal output.

    Standard resolution is 5 µm (0.005 mm).

    With IP67 Protection Class, they are unaffected by oil, water, dust, etc.

    The cables are protected by a steel galvanized spiral conduit to prevent damage under harsh production conditions.

    Standard cable lengths are 3.5 and 5 meters. Optional lengths up to 50 meters can be manufactured in a single piece.

    EMS320 Magnetic Scales can be used with EMOS80, EMOS100 Digital Displays, PLCs, CNC Systems, Digital Counters, and all devices with encoder reading capabilities.

    Thanks to the scrapers integrated into the sensor body, they are specially protected against external elements such as dust, dirt, and chips that may accumulate on the magnetic band or profile surface.
