    WSGBOX-01

    This is an operator panel with HDMI output, developed for use in industrial applications. This product comes with a real-time clock (RTC) as a standard feature. Its user-friendly software has an extensive library and supports all known PLCs.

    With the USB Host feature, data can be logged, programs can be loaded, and keyboard / mouse / webcam can be connected.

    This model, with an Ethernet port supporting MODBUS TCP communication, allows fast and secure communication with GLC39X and GLC49X series CPUs and easy integration into SCADA applications.

    With VNC software, this model can be accessed via local network or the internet through Windows, iOS, and Android platforms, providing monitoring and control.

    HDMI V1.4 FHD (1920×1080), 32bit 1 GHz RISC Cortex-A9 Processor, 100M Ethernet port, 2 USB Host Ports

    Display Output HDMI V1.4 FHD
    Resolution 1920 x 1080
    Processor 32 Bit RISC Cortex-A9 1GHz
    Memory 512MB DDR3 + 4GB eMMC
    RTC Available
    Expansion Memory 2 USB Hosts
    Printer Port USB Host
    Ethernet Available
    Program Upload USB Host / RS-232 / Ethernet
    COM Ports COM0: RS-232, RS-485, RS-422
    COM1: RS-485
    COM2: RS-232
    Power Consumption 2.4W
    Operating Voltage 24VDC
    Input Range 10VDC – 28VDC
    Instant Power Loss <3ms
    Scale Isolation Resistance >50MΩ (500VDC)
    Dielectric Strength Test 500VAC 1 minute
    Housing Material Metal
    Dimensions (mm) 133 x 104 x 30.2
    Mounting DIN Rail (35mm), VESA Bracket (75×75mm)
    Weight (g) 470
    Operating Temperature 0 to 50°C
    Operating Humidity 10%rH to 90%rH, non-condensing
    Storage Temperature -30 to 80°C
    Storage Humidity 10%rH to 90%rH, non-condensing
    Shock Resistance Test 10Hz to 25Hz (X,Y,Z directions, 30 minutes)
    Cooling Method Natural air
    Protection Class IP20
    Certifications CE Marked
