    GHS-043E

    GHS-043E is a 16.77M color TFT touch operator panel developed for industrial applications. This product comes with a real-time clock (RTC) as standard. Its user-friendly software has a wide library and supports all known PLCs.

    It is compatible with HP LaserJet P1100 series printers.

    With the PDF Viewer function, PDF files can be viewed.

    4.3" TFT (16:9W) Screen Size, 800 x 480 Screen Resolution, ARM Cortex-A7 Dual Core 1GHz Processor, 256 MB NAND Flash +128 MB DDR3 Memory

    Display Type 4.3" TFT
    Resolution 800 x 480
    Color 16.77M
    Backlight LED
    Brightness 500cd/m²
    Backlight Lifetime >30,000 hours
    Touch Screen 4-wire precise resistance circuit
    Processor ARM Cortex-A7 Dual Core 1GHz
    Memory 256 MB NAND Flash +128 MB DDR3 Memory
    RTC Yes
    Expansion Memory -
    Printer Port USB Slave (Pictbridge)
    Ethernet Yes
    Program Uploading MICRO USB / RS-232
    COM Port COM0: RS-232, RS-485, RS-422
    COM2: RS-232
    Power Consumption 2.4W
    Operating Voltage 24VDC
    Input Range 10VDC – 28VDC
    Instant Power Cutoff <3ms
    Insulation Resistance >50MΩ (500VDC)
    Dielectric Strength Test 500VAC 1 minute
    Case Material Engineering Plastic
    Dimensions (mm) 132 x 102 x 33
    Panel Cutout Dimensions (mm) 119 x 93
    Weight (kg) 0.21
    Operating Temperature 0 to 50°C
    Operating Environment Humidity 10%rH to 90%rH, without condensation
    Storage Temperature -20 to 60°C
    Storage Humidity 10%rH to 90%rH, without condensation
    Impact Resistance Test 10Hz to 25Hz (X,Y,Z axes, 30 minutes)
    Cooling Method Air cooling
    Protection Class IP65 (front panel)
    Certifications CE marked, EN61000-6-2:2005/EN61000-6-4:2007+A1:2011
