    MICNO 0.75 kW~630 kW

    380VAC powered, offers 150% starting torque with V/F and open-loop vector control. It features 7 digital inputs, 2 analog inputs/outputs, 2 relay outputs, PID, and torque control. With Modbus RTU supported RS-485 port, portable panel, autotune, built-in brake chopper, and up to 3000Hz frequency, it is efficient in fan-pump applications.

    PDF

    Whatsapp
    Emos Group Electronic Machinery Industry | INDUSTRIAL ELECTRONICS, Linear Scales, Sensors, Flow Meters, Central Lubrication Systems, Rotary Encoders, Couplings, Indicators, Potentiometers, Industrial Automation and Control, MACHINE TOOLS, Surface Grinding, EDM Erosion, Band Saws, Boring Machines, Vertical Shapers, Slotting Machines, Tapping Machines, Guillotines, Welding, Compressors, 3D Printers, CNC, Lathe, Milling, Drilling, Presses, Laser, Tool Grinding, QUALITY CONTROL, Single-Axis Measuring Tables, 2-Axis Measuring Tables, 3D Coordinate Measuring Machines, Nuve Coordinate Measuring Tables, Meter Calibration Tables, Length Measuring Tables, Profile Projectors, Video Measuring Devices, Height Gauges, DIGITAL MEASUREMENT SYSTEMS, Digital Measuring Scales, Digital Indicators, Reader Sensors, Digital Measurement System Packages, Battery-Powered Digital Measurement Systems, CNC SPARE PARTS, 3D Sensor, Test Calibration, Spindle Encoder, Battery, Relay, Lubrication Pumps, Foot Pedal, Sensors, Electronic Modules, Switch, Resistor, Power Supplies, Cables, Servo Motors, Encoders, Probes, Magnetic Chucks, Dividers, Handwheels, Mode Switches, Rotary Joints, Slideway Oil Separators, Pulstat Holders, Card Holders, MACHINE LIGHTING, CNC LED Lighting Lamps, Glass Tube LED Lamps, Fluorescent Glass Tube Lamps, LED Lamps with Articulated Arms, Halogen Lamps with Articulated Arms, Flexible Body LED Lamps, Magnetic Base LED Lamps, Flexible Body Halogen Lamps, Magnifying Articulated Lamps
    Önceki Ürün Sonraki Ürün

    MICNO SPEED CONTROL DEVICE – AC DRIVE – INVERTER

    3 x 380VAC (+/- 15%) 50/60Hz supply voltage

    V/F and open-loop vector control

    High starting torque (150% at 0.5Hz)

    7 PNP/NPN digital inputs

    2 relay outputs

    2 analog inputs: 0-10VDC / 4-20mA

    2 analog outputs: 0-10VDC / 4-20mA

    PID control

    Open-loop torque control

    Built-in RS-485 communication port supporting Modbus RTU

    Easy-to-use interface

    Removable operator panel (can be mounted on the panel top with a standard ethernet cable)

    Dual operation mode for cost-effective fan – pump applications

    Autotune feature for automatic motor parameter adjustment

    Built-in brake chopper (up to 30kW)

    Adjustable output frequency up to 3000Hz

    Supply Voltage 3×380 V (Three-phase)
    Supply Frequency 47 Hz to 63 Hz
    Control Mode V/f control mode, Sensorless vector control mode, Torque control mode
    Frequency Range V/f control: 0 Hz to 3000.0 Hz
    Vector control: 0 Hz to 300.00 Hz
    Adjustment Resolution Digital: 0.01 Hz, Analog: Maximum frequency / 2000
    Overload Current Rate G model: 150% for 60 sec, 180% for 10 sec, 200% for 3 sec
    P model: 120% for 60 sec, 150% for 10 sec, 180% for 3 sec
    Acceleration and Deceleration 0.1 sec to 3600.0 sec
    Starting Torque 150% at 0.5 Hz in vector control mode
    150% at 1 Hz in V/f control mode
    DC Braking Available
    PID Function Available
    Communication RS-485 communication supporting standard MODBUS RTU protocol
    Built-in Braking Built-in brake chopper up to 30 kW
    Digital Inputs 6 selectable PNP or NPN digital inputs
    Relay Output 2 programmable relay outputs
    Fast Pulse Input 1 fast pulse input (can also be used as a digital input)
    Fast Pulse Output 1 fast pulse output (can also be used as a transistor output)
    Analog Input 1 selectable analog input (4-20 mA or 0-10 V)
    Analog Output 1 programmable selectable analog output (4-20 mA or 0-10 V)
    Operating Temperature -10°C to 50°C (If the ambient temperature is above 40°C, carrier frequency should be below 2.0 kHz)
    Storage Temperature -20°C to 60°C
    Humidity Under 90% Rh, (without condensation)
    Protection Class IP20



    Product Code Power Current Information (Amps) Suitable Brake Resistor Width (mm) Height (mm) Depth (mm)
    MICNO-00075H 0.75 kW 2.1 A / 3.8 A 300W - 300Ω 110 185 153
    MICNO-00150H 1.5 kW 3.8 A / 6 A 300W - 300Ω 110 185 153
    MICNO-00220H 2.2 kW 6 A / 9 A 300W - 300Ω 110 185 153
    MICNO-00370H 3.7 kW / 5.5 kW 9 A / 13 A 600W - 130Ω 110 185 153
    MICNO-00550H 5.5 kW / 7.5 kW 13 A / 17 A 600W - 130Ω 135 240 173
    MICNO-00750H 7.5 kW / 11 kW 17 A / 25 A 1400W - 80Ω 135 240 173
    MICNO-01100H 11 kW / 15 kW 25 A / 32 A 1400W - 80Ω 170 285 176
    MICNO-01500H 15 kW / 18.5 kW 32 A / 37 A 3000W - 32Ω 200 330 180
    MICNO-01850H 18.5 kW / 22 kW 37 A / 45 A 3000W - 32Ω 200 330 180
    MICNO-02200H 22 kW / 30 kW 45 A / 60 A 3000W - 32Ω 225 400 190
    MICNO-03000H 30 kW / 37 kW 60 A / 75 A 4000W - 25Ω 255 440 215
    MICNO-03700HS 37 kW / 45 kW 75 A / 90 A - 255 440 210
    MICNO-04500HS 45 kW / 55 kW 90 A / 110 A - 255 440 210
    MICNO-05500H 55 kW / 75 kW 110 A / 150 A - 320 600 330
    MICNO-07500H 75 kW / 90 kW 150 A / 176 A - 320 600 330
    MICNO-09000H 90 kW / 110 kW 176 A / 210 A - 320 715 330
    MICNO-11000HS 110 kW / 132 kW 210 A / 253 A - 320 600 330
    MICNO-13200H 132 kW / 160 kW 253 A / 304 A - 480 790 385
    MICNO-16000H 160 kW / 185 kW 304 A / 340 A - 480 790 385
    MICNO-18500H 185 kW / 200 kW 340 A / 377 A - 480 790 385
    MICNO-20000H 200 kW / 220 kW 377 A / 423 A - 480 790 385
    MICNO-22000H 220 kW / 250 kW 423 A / 465 A - 700 970 408
    MICNO-25000H 250 kW / 280 kW 465 A / 520 A - 700 970 408
    MICNO-28000H 280 kW / 315 kW 520 A / 585 A - 700 970 408
    MICNO-31500H 315 kW / 350 kW 585 A / 640 A - 700 970 408
