    All-5 Two-line AC (barrel type) lubrication pump

    All-5 electric grease pumps are produced only for lubrication purposes.The direction valve is integrated into the pump design to operate in two -line lubrication systems.

    PDF

    Whatsapp
    Emos Group Electronic Machinery Industry | INDUSTRIAL ELECTRONICS, Linear Scales, Sensors, Flow Meters, Central Lubrication Systems, Rotary Encoders, Couplings, Indicators, Potentiometers, Industrial Automation and Control, MACHINE TOOLS, Surface Grinding, EDM Erosion, Band Saws, Boring Machines, Vertical Shapers, Slotting Machines, Tapping Machines, Guillotines, Welding, Compressors, 3D Printers, CNC, Lathe, Milling, Drilling, Presses, Laser, Tool Grinding, QUALITY CONTROL, Single-Axis Measuring Tables, 2-Axis Measuring Tables, 3D Coordinate Measuring Machines, Nuve Coordinate Measuring Tables, Meter Calibration Tables, Length Measuring Tables, Profile Projectors, Video Measuring Devices, Height Gauges, DIGITAL MEASUREMENT SYSTEMS, Digital Measuring Scales, Digital Indicators, Reader Sensors, Digital Measurement System Packages, Battery-Powered Digital Measurement Systems, CNC SPARE PARTS, 3D Sensor, Test Calibration, Spindle Encoder, Battery, Relay, Lubrication Pumps, Foot Pedal, Sensors, Electronic Modules, Switch, Resistor, Power Supplies, Cables, Servo Motors, Encoders, Probes, Magnetic Chucks, Dividers, Handwheels, Mode Switches, Rotary Joints, Slideway Oil Separators, Pulstat Holders, Card Holders, MACHINE LIGHTING, CNC LED Lighting Lamps, Glass Tube LED Lamps, Fluorescent Glass Tube Lamps, LED Lamps with Articulated Arms, Halogen Lamps with Articulated Arms, Flexible Body LED Lamps, Magnetic Base LED Lamps, Flexible Body Halogen Lamps, Magnifying Articulated Lamps
    Önceki Ürün Sonraki Ürün

    All-5 Two-line AC (barrel type) lubrication pump

    All-5 electric grease pumps are produced only for lubrication purposes.

    The direction valve is integrated into the pump design to operate in two -line lubrication systems.

    The displacement of the pump is variable to provide the necessary lubrication needs.

    There is no lubricant store in the pump system.

    Standard grease barrels can be used as a reservoir.

    Pump systems dive lengths can be produced for different barrel volumes.

    All-5 pumps are produced with 3 different size grease piston options.

    Each piston gives a different amount of grease and pressure value to the pump output.

    ATTENTION :All5 pumps are produced only for lubrication purposes, so it is not appropriate to operate the pump for more than 5 minutes.

    Working temperature -25 ° ...+80 ° C
    Protection class IP54
    Motor type 380 V AC
    Max.Pressure 200 bars
    Oil class NLGI 00 (-30 ° C to -10 ° C), NLGI 0 (0 ° C to 0 ° C), NLGI 1 (0 ° C to 10 ° C)
    Pump Element displacement (Ø12 piston) 160 cm³/minute, (Ø16 piston) 280 cm³/minute, (Ø20 piston) 445 cm³/minute
    HUZNE CAPACITES No reservoirs.(Standard grease barrels can be used as chamber.)
