    ESGD1

    Single-phase 7-30V DC Input Voltage 3-40V DC Load Voltage Narrow Panel Type

    PDF

    Whatsapp
    Emos Group Electronic Machinery Industry | INDUSTRIAL ELECTRONICS, Linear Scales, Sensors, Flow Meters, Central Lubrication Systems, Rotary Encoders, Couplings, Indicators, Potentiometers, Industrial Automation and Control, MACHINE TOOLS, Surface Grinding, EDM Erosion, Band Saws, Boring Machines, Vertical Shapers, Slotting Machines, Tapping Machines, Guillotines, Welding, Compressors, 3D Printers, CNC, Lathe, Milling, Drilling, Presses, Laser, Tool Grinding, QUALITY CONTROL, Single-Axis Measuring Tables, 2-Axis Measuring Tables, 3D Coordinate Measuring Machines, Nuve Coordinate Measuring Tables, Meter Calibration Tables, Length Measuring Tables, Profile Projectors, Video Measuring Devices, Height Gauges, DIGITAL MEASUREMENT SYSTEMS, Digital Measuring Scales, Digital Indicators, Reader Sensors, Digital Measurement System Packages, Battery-Powered Digital Measurement Systems, CNC SPARE PARTS, 3D Sensor, Test Calibration, Spindle Encoder, Battery, Relay, Lubrication Pumps, Foot Pedal, Sensors, Electronic Modules, Switch, Resistor, Power Supplies, Cables, Servo Motors, Encoders, Probes, Magnetic Chucks, Dividers, Handwheels, Mode Switches, Rotary Joints, Slideway Oil Separators, Pulstat Holders, Card Holders, MACHINE LIGHTING, CNC LED Lighting Lamps, Glass Tube LED Lamps, Fluorescent Glass Tube Lamps, LED Lamps with Articulated Arms, Halogen Lamps with Articulated Arms, Flexible Body LED Lamps, Magnetic Base LED Lamps, Flexible Body Halogen Lamps, Magnifying Articulated Lamps
    Önceki Ürün

    ESGD1

    40A AC load current

    3-40V DC load voltage

    7-30V DC input voltage

    LED indicator for input voltage

    Varistor protection for peak voltages

    CE certified according to EN standards

    Ambient/Storage Temperature -25...60 ºC / -30...100 ºC
    Relative Humidity Operates up to 50% at 40 ºC, increases as temperature decreases, operates at 90% humidity at 20 ºC
    Protection Class According to EN 60529 standard: IP20
    Altitude Maximum 1000m
    Input Voltage 7-30V DC
    Transmission Voltage >7V DC
    Cutoff Voltage <6V DC
    Input Current <20mA DC
    Transmission Time 5ms
    Cutoff Time 5ms
    LED Indicator LED lights up when transmission voltage is >6V DC
    Load Current (A DC) EPGD1-440Z: 40
    Load Voltage (V DC) 3-40
    Frequency (Hz) 100
    Mounting Type Mounted to the panel with M4 screws
    Dimensions W24xH101xD29 mm
    Weight 95g (including packaging)
    Enclosure Materials Self-extinguishing plastics used
