    Emos Group Industrial Electronics Industrial Automation and Control Solar Pump Drive SPIN 0.40 kW~11 kW
    Emos Group Electronic Machinery Industry | INDUSTRIAL ELECTRONICS, Linear Scales, Sensors, Flow Meters, Central Lubrication Systems, Rotary Encoders, Couplings, Indicators, Potentiometers, Industrial Automation and Control, MACHINE TOOLS, Surface Grinding, EDM Erosion, Band Saws, Boring Machines, Vertical Shapers, Slotting Machines, Tapping Machines, Guillotines, Welding, Compressors, 3D Printers, CNC, Lathe, Milling, Drilling, Presses, Laser, Tool Grinding, QUALITY CONTROL, Single-Axis Measuring Tables, 2-Axis Measuring Tables, 3D Coordinate Measuring Machines, Nuve Coordinate Measuring Tables, Meter Calibration Tables, Length Measuring Tables, Profile Projectors, Video Measuring Devices, Height Gauges, DIGITAL MEASUREMENT SYSTEMS, Digital Measuring Scales, Digital Indicators, Reader Sensors, Digital Measurement System Packages, Battery-Powered Digital Measurement Systems, CNC SPARE PARTS, 3D Sensor, Test Calibration, Spindle Encoder, Battery, Relay, Lubrication Pumps, Foot Pedal, Sensors, Electronic Modules, Switch, Resistor, Power Supplies, Cables, Servo Motors, Encoders, Probes, Magnetic Chucks, Dividers, Handwheels, Mode Switches, Rotary Joints, Slideway Oil Separators, Pulstat Holders, Card Holders, MACHINE LIGHTING, CNC LED Lighting Lamps, Glass Tube LED Lamps, Fluorescent Glass Tube Lamps, LED Lamps with Articulated Arms, Halogen Lamps with Articulated Arms, Flexible Body LED Lamps, Magnetic Base LED Lamps, Flexible Body Halogen Lamps, Magnifying Articulated Lamps

    SPIN 0.40 kW~11 kW

    Compatible with a voltage range of 200-450VDC (for 3x220VAC pumps), offering V/F and vector control. Solar pump functions: MPPT, dry running, water level, and low solar warning. Provides energy balance with 7 digital inputs, 2 analog inputs/outputs, 2 relay outputs, and RS485-supported Modbus RTU. EMC filter is available in models above 37kW.

    PDF

    Whatsapp
    Emos Group Electronic Machinery Industry | INDUSTRIAL ELECTRONICS, Linear Scales, Sensors, Flow Meters, Central Lubrication Systems, Rotary Encoders, Couplings, Indicators, Potentiometers, Industrial Automation and Control, MACHINE TOOLS, Surface Grinding, EDM Erosion, Band Saws, Boring Machines, Vertical Shapers, Slotting Machines, Tapping Machines, Guillotines, Welding, Compressors, 3D Printers, CNC, Lathe, Milling, Drilling, Presses, Laser, Tool Grinding, QUALITY CONTROL, Single-Axis Measuring Tables, 2-Axis Measuring Tables, 3D Coordinate Measuring Machines, Nuve Coordinate Measuring Tables, Meter Calibration Tables, Length Measuring Tables, Profile Projectors, Video Measuring Devices, Height Gauges, DIGITAL MEASUREMENT SYSTEMS, Digital Measuring Scales, Digital Indicators, Reader Sensors, Digital Measurement System Packages, Battery-Powered Digital Measurement Systems, CNC SPARE PARTS, 3D Sensor, Test Calibration, Spindle Encoder, Battery, Relay, Lubrication Pumps, Foot Pedal, Sensors, Electronic Modules, Switch, Resistor, Power Supplies, Cables, Servo Motors, Encoders, Probes, Magnetic Chucks, Dividers, Handwheels, Mode Switches, Rotary Joints, Slideway Oil Separators, Pulstat Holders, Card Holders, MACHINE LIGHTING, CNC LED Lighting Lamps, Glass Tube LED Lamps, Fluorescent Glass Tube Lamps, LED Lamps with Articulated Arms, Halogen Lamps with Articulated Arms, Flexible Body LED Lamps, Magnetic Base LED Lamps, Flexible Body Halogen Lamps, Magnifying Articulated Lamps
    Sonraki Ürün

    SPIN PUMP DRIVES

    Wide DC voltage range (min/max):

    - 200-450VDC (3x220VAC Pump)

    V/F and vector control

    Solar pump special functions:

    - Built-in MPPT function

    - Dry running protection

    - Water level sensor protection

    - Low solar level warning

    7 programmable digital inputs

    2 programmable relay outputs

    RS485 communication port supporting Modbus RTU

    2 analog inputs 0-10 V / 0-20 mA

    Analog input for water source level

    2 analog outputs 0-10 V / 0-20 mA

    Built-in EMC filter for models above 37kW

    Automatic energy balancing with common DC Bus

    Supply Voltage 200-450VDC (3x220VAC Pump)
    Supply Frequency Between 47 Hz and 63 Hz
    Control Mode V/f control mode
    Frequency Range Between 0 Hz and 3000 Hz
    Adjustment Resolution Digital: 0.01 Hz, Analog: Maximum frequency / 2000
    Overload Current Ratio 150% for 60 seconds, 180% for 10 seconds, 200% for 3 seconds
    Acceleration and Deceleration Between 0.1 sec and 3600.0 sec
    Starting Torque 150% at 1 Hz
    DC Braking Yes
    PID Function Yes
    Communication RS-485 communication supporting standard MODBUS RTU protocol
    Digital Input 4 selectable PNP or NPN digital inputs
    Relay Output 1 programmable relay output
    Fast Pulse Input 1 fast pulse input
    Analog Input 1 selectable 4-20 mA or 0-10 V analog input
    Analog Output 1 programmable 4-20 mA or 0-10 V selectable analog output
    Operating Temperature -10°C to 40°C
    Storage Temperature -20°C to 60°C
    Humidity Under 90% RH, (without condensation)



    SPIN-00040S 80x150x124
    SPIN-00075S 80x150x124
    SPIN-00150S 80x150x124
    SPIN-00220S 110x185x153
    SPIN-00400S 135x240x173
    SPIN-00550S 170x314x167
    SPIN-00750S 200x330x80
    SPIN-01100S 225x400x185
