    Power Regulator with 4-20mA Input Signal, 180-320V AC, 180-480V AC, 180-500V AC Load Voltage

    PDF

    Whatsapp
    Emos Group Electronic Machinery Industry | INDUSTRIAL ELECTRONICS, Linear Scales, Sensors, Flow Meters, Central Lubrication Systems, Rotary Encoders, Couplings, Indicators, Potentiometers, Industrial Automation and Control, MACHINE TOOLS, Surface Grinding, EDM Erosion, Band Saws, Boring Machines, Vertical Shapers, Slotting Machines, Tapping Machines, Guillotines, Welding, Compressors, 3D Printers, CNC, Lathe, Milling, Drilling, Presses, Laser, Tool Grinding, QUALITY CONTROL, Single-Axis Measuring Tables, 2-Axis Measuring Tables, 3D Coordinate Measuring Machines, Nuve Coordinate Measuring Tables, Meter Calibration Tables, Length Measuring Tables, Profile Projectors, Video Measuring Devices, Height Gauges, DIGITAL MEASUREMENT SYSTEMS, Digital Measuring Scales, Digital Indicators, Reader Sensors, Digital Measurement System Packages, Battery-Powered Digital Measurement Systems, CNC SPARE PARTS, 3D Sensor, Test Calibration, Spindle Encoder, Battery, Relay, Lubrication Pumps, Foot Pedal, Sensors, Electronic Modules, Switch, Resistor, Power Supplies, Cables, Servo Motors, Encoders, Probes, Magnetic Chucks, Dividers, Handwheels, Mode Switches, Rotary Joints, Slideway Oil Separators, Pulstat Holders, Card Holders, MACHINE LIGHTING, CNC LED Lighting Lamps, Glass Tube LED Lamps, Fluorescent Glass Tube Lamps, LED Lamps with Articulated Arms, Halogen Lamps with Articulated Arms, Flexible Body LED Lamps, Magnetic Base LED Lamps, Flexible Body Halogen Lamps, Magnifying Articulated Lamps
    Önceki Ürün Sonraki Ürün

    EFSC

    4-20mA or 0-10V Input type

    2A-4A-6A-8A AC load current

    Zero-Cross control

    CE marked according to EN standards

    Supply Voltage 230V AC +10%-20%, 50/60Hz
    Power Consumption 1.5VA
    Connection 2.5mm² terminal
    EMC EN 61326-1: 2021
    EFSC-02 5x20mm 2.5A Time Delay
    EFSC-04 5x20mm 5A Time Delay
    EFSC-06 5x20mm 8A Time Delay
    EFSC-08 5x20mm 10A Time Delay
    Signal Type 0-10V DC, 4-20mA DC
    Input Impedance 180kΩ for 0-10V DC, 100Ω for 4-20mA DC
    Min. Input Signal Amplitude 5V
    Max. Input Signal Amplitude 9.3V
    Operating Ambient Temperature -10...+50 °C
    Storage Ambient Temperature -20...+85 °C
    Operating and Storage Ambient Humidity 10...90 % (non-condensing)
