    GSS3-3RS / GSS3-3EC

    It works with 1-2 kW motors to provide position, speed, and torque control. Nikon Encoder feedback, Modbus RTU, and EtherCat communication are supported. With 7 digital inputs, 5 digital outputs, 2 analog inputs, and protection functions, it ensures reliable performance in automation applications.

    PDF

    Whatsapp
    Emos Group Electronic Machinery Industry | INDUSTRIAL ELECTRONICS, Linear Scales, Sensors, Flow Meters, Central Lubrication Systems, Rotary Encoders, Couplings, Indicators, Potentiometers, Industrial Automation and Control, MACHINE TOOLS, Surface Grinding, EDM Erosion, Band Saws, Boring Machines, Vertical Shapers, Slotting Machines, Tapping Machines, Guillotines, Welding, Compressors, 3D Printers, CNC, Lathe, Milling, Drilling, Presses, Laser, Tool Grinding, QUALITY CONTROL, Single-Axis Measuring Tables, 2-Axis Measuring Tables, 3D Coordinate Measuring Machines, Nuve Coordinate Measuring Tables, Meter Calibration Tables, Length Measuring Tables, Profile Projectors, Video Measuring Devices, Height Gauges, DIGITAL MEASUREMENT SYSTEMS, Digital Measuring Scales, Digital Indicators, Reader Sensors, Digital Measurement System Packages, Battery-Powered Digital Measurement Systems, CNC SPARE PARTS, 3D Sensor, Test Calibration, Spindle Encoder, Battery, Relay, Lubrication Pumps, Foot Pedal, Sensors, Electronic Modules, Switch, Resistor, Power Supplies, Cables, Servo Motors, Encoders, Probes, Magnetic Chucks, Dividers, Handwheels, Mode Switches, Rotary Joints, Slideway Oil Separators, Pulstat Holders, Card Holders, MACHINE LIGHTING, CNC LED Lighting Lamps, Glass Tube LED Lamps, Fluorescent Glass Tube Lamps, LED Lamps with Articulated Arms, Halogen Lamps with Articulated Arms, Flexible Body LED Lamps, Magnetic Base LED Lamps, Flexible Body Halogen Lamps, Magnifying Articulated Lamps
    Önceki Ürün Sonraki Ürün

    GSS3-3RS / GSS3-3EC SERVO DRIVER

    Servo systems made of natural magnet motors with microprocessor and semiconductor technology are becoming increasingly cost-effective, providing precise measurement, stable speed control, torque control, rapid acceleration and deceleration for automation systems.

    Our servo systems, offered to the machinery manufacturing sector, are widely used in machines such as Test devices, Press, Cutting, Filling, Packaging, Plastic, Food, Textile, CNC, Woodworking, etc.

    For 1kW, 1.5kW, and 2kW motors

    Feedback with 20 Bit Nikon brand Encoder

    Single-phase 200-240VAC ±10%, 50-60Hz ±3% Supply Voltage

    Position / Speed / Torque Control Modes

    Ability to create a 32-step Position Table

    High-speed pulse inputs, Open-collector (500 kHz), Differential Mode (4 MHz)

    Pulse + Direction, CCW + CW, Phase A + Phase B (5V to 24V) Pulse Command Types

    Ability to adjust speed and torque setpoints with analog inputs and internal parameters

    Easy adjustment of gain parameters

    5V internal power output

    Easy commissioning with PC software or internal keypad and display

    Additional RS-232 communication port for PC software

    2MHz Encoder output signal

    Ability to switch between Position, Speed, Torque modes

    Online adjustable Electronic Gearbox

    Torque/Speed limits

    Built-in position and Homing function

    Modbus RTU communication (GSS3-3RS)

    High-speed communication with EtherCat communication port (GSS3-3EC)

    7 selectable PNP/NPN digital inputs

    5 digital outputs

    2 -10V...+10V analog inputs

    Overvoltage, Low voltage, Short circuit, Motor overheating, Servo driver overheating protection functions

    Supply Voltage 1×200-240 VAC (Single-phase)
    Supply Frequency 50 Hz to 60 Hz ±3%
    Control Circuit Voltage 200-240 VAC (Single-phase)
    Nominal Current 10A
    Peak Current 27.5A
    Feedback Signal 20 Bit Communication Enabled Encoder
    Brake Resistor External brake may be used depending on application
    Brake Resistor Threshold Voltage 380 VDC (+/- 5 V)
    Overvoltage Alarm Threshold 400 VDC (+/- 5 V)
    Undervoltage Alarm Threshold 200 VDC (+/- 5 V)
    Cooling Method Natural air cooling
    Weight (kg) 1.33
    RS-232 Port Up to 115200 bps PC serial-Servo Driver communication port
    RS-485 Port Up to 115200 bps ModBUS RTU communication port (GSS3-3RS)
    EtherCAT Port High-speed EtherCAT Slave communication port (GSS3-3EC)
    Digital Inputs 7 selectable PNP or NPN digital inputs
    Digital Outputs 5 digital outputs
    Analog Input 2 -10V...+10V analog inputs (can be used for speed and torque control)
    Encoder Signal Output Optional (max. 10 MHz)
    Operating Temperature 0°C to 40°C
    Storage Temperature -10°C to 70°C
    Humidity Under 90% Rh (without condensation)
    Protection Class IP20
    Installation Conditions Dust-free, dry, and closed environment
    Installation Type Vertical installation
    Altitude Up to 1000 meters
    Atmospheric Pressure Between 86 kPa and 106 kPa
    Vibration 5.9 m/s² (0.6 G), between 10 Hz and 55 Hz



    Motor Code Power Cable Encoder Cable
    GSM130F-1000W-20B-20D-MC GMK-XX-MC4 GEK-XX-GC0-MC
    GSM130F-1000W-20B-20D-MC-B GMK-XX-MC4-B GEK-XX-GC0-MC
    GSM130F-1500W-20B-20D-MC GMK-XX-MC4 GEK-XX-GC0-MC
    GSM130F-1500W-20B-20D-MC-B GMK-XX-MC4-B GEK-XX-GC0-MC
    GSM130F-2000W-20B-20D-MC GMK-XX-MC4 GEK-XX-GC0-MC
    GSM130F-2000W-20B-20D-MC-B GMK-XX-MC4-B GEK-XX-GC0-MC

    - The XX in power and encoder cables indicates the cable length. For 5 meters, write 05; for 15 meters, write 15.

    - For GSM60F-0200W-20B-30D-KLY-B, GSM60F-0400W-20B-30D-KLY-B, and GSM60F-0750W-20B-30D-KLY-B motors, an additional brake cable must be purchased.
